Total Video Inputs
- 40
Total Video Outputs
- 24
SDI Rates
- 1.5G, 3G
Total Audio Inputs
- 2 x balanced 1/4 inch Jack,
- 1 x 32 stereo channel BNC MADI in.
- 1 x 5 pin XLR Talkback.
Total Audio Outputs
- 2 x balanced 1/4 inch Jack,
- 2 x 32 stereo channel BNC MADI out.
- 1 x 5 pin XLR Talkback.
SDI Audio Inputs
- 2 Ch embedded audio on all SDI inputs.
SDI Audio Outputs
- 2 Ch embedded audio on all SDI outputs.
Timecode Connections
- None
Reference Input
- Tri-Sync or Black Burst.
Video Input Re-Sync
- On all 40 inputs.
Frame Rate and Format Converters
- On all 40 inputs.
SDI Aux Outputs
- Any of the 24 SDI outputs.
SDI Preview Outputs
- Any of the 24 SDI outputs.
SDI Program Outputs
- Any of the 24 SDI outputs.
Down Converted SDI Program Output
- None
Webcam Output
- 1 x USB-C supporting 720p or 1080p at PGM frame rate.
Total Multi Views
- 4 x 3G-SDI
Remote
- RJ12 supports RS-422
Control Panel Connection
- Ethernet. Direct connection between panel and chassis, or via network.
Internal Timecode Generator
- Yes
Talkback
- RJ45 for 3rd party talkback systems.
Tally Output
- Added via ethernet connection to Blackmagic Design GPI and Tally Interface product. (Not included).
Ethernet
- Supports 10/100/1000 BASE-T.
Computer Interface
- 1 x USB-C supports USB 2.0
